Place of Origin:
China
Brand Name:
ZH / Qireal
Model Number:
FYJ 70 TF
FYJ70TF Pillow Block Bearing Unit YAR 214-2F Bearing FYJ 514
FYJ 70 TF Pillow Block Bearing Unit YAR 214-2F Bearing FYJ 514 Parts
Product Introduction:
FYJ 70 TF Pillow Block Bearing / Pillow Housings: Supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubriexcavatorion. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required.
Drawing
Deep Groove Ball Bearing
Tapered Roller Bearing
Spherical Roller Bearing
Thin-section/wall Ball Bearing
Angular Contact Ball Bearing
Thrust Ball Bearing
Cylindrical Roller Bearing
Thrust Roller Bearing
Full Complement Roller Bearing
1.Cylindrical roller bearing
2.Thrust ball bearing
3.Thrust roller bearing
4.Tapered roller bearing
5.Spherical roller bearing
6.Self-aligning ball bearing
7.Angular contact ball bearing
8.Joint bearing
| Model | Size(mm) | |||||
| d | D | J | A2 | N | A | |
| UCF201 | 12 | 86 | 64 | 15 | 12 | 25.5 |
| UCF202 | 15 | 86 | 64 | 15 | 12 | 26.5 |
| UCF203 | 17 | 86 | 64 | 15 | 12 | 27.5 |
| UCF204 | 20 | 86 | 64 | 15 | 12 | 28.5 |
| UCF205 | 25 | 95 | 70 | 16 | 12 | 27 |
| UCF206 | 30 | 108 | 83 | 18 | 12 | 31 |
| UCF207 | 35 | 117 | 92 | 19 | 14 | 34 |
| UCF208 | 40 | 130 | 102 | 21 | 16 | 36 |
| UCF209 | 45 | 137 | 105 | 22 | 18 | 38 |
| UCF210 | 50 | 143 | 111 | 22 | 20 | 40 |
| UCF211 | 55 | 162 | 130 | 25 | 22 | 43 |
| UCF212 | 60 | 175 | 143 | 29 | 22 | 48 |
| UCF213 | 65 | 187 | 149 | 30 | 22 | 50 |
| UCF214 | 70 | 193 | 152 | 31 | 22 | 54 |
