Place of Origin:
China
Brand Name:
Z&H
Model Number:
FY70TF
| Brand | Z&H |
| Item Number | FY70TF SKF |
| Technical details | (TF)TF=Y-Bearing Of Series YAR2-2F (Inner Ring Extended At Both Sides, Grub Screw Locking), Standard Seal And Plain Flinger At Each Side. |
| excavatoregory | Housing and Bearing (assembly) |
| MPN | FY70TF |
| Inner (d) MM | 70,00 |
| Weight (kg) | 5.493 |
| Seal | 2F - Standard Seal for Y-bearings |
| Lubriexcavatorion | Standard Lubriexcavatorion |
| Special Treatment | No Special Treatment |
| Model | Size(mm) | |||||
| d | D | J | A2 | N | A | |
| UCF201 | 12 | 86 | 64 | 15 | 12 | 25.5 |
| UCF202 | 15 | 86 | 64 | 15 | 12 | 26.5 |
| UCF203 | 17 | 86 | 64 | 15 | 12 | 27.5 |
| UCF204 | 20 | 86 | 64 | 15 | 12 | 28.5 |
| UCF205 | 25 | 95 | 70 | 16 | 12 | 27 |
| UCF206 | 30 | 108 | 83 | 18 | 12 | 31 |
| UCF207 | 35 | 117 | 92 | 19 | 14 | 34 |
| UCF208 | 40 | 130 | 102 | 21 | 16 | 36 |
| UCF209 | 45 | 137 | 105 | 22 | 18 | 38 |
| UCF210 | 50 | 143 | 111 | 22 | 20 | 40 |
| UCF211 | 55 | 162 | 130 | 25 | 22 | 43 |
| UCF212 | 60 | 175 | 143 | 29 | 22 | 48 |
| UCF213 | 65 | 187 | 149 | 30 | 22 | 50 |
| UCF214 | 70 | 193 | 152 | 31 | 22 | 54 |
ZhongHong Bearing Manufacturing Co.Ltd., produces a wide range of ball and roller bearings for automotive making, Ferrous Metallurgy, Chemical Machinery and Machine Manufacturing in its primary plants in China mainland. Our main bearing products include deep groove ball bearings, tapered roller bearings, cylindrical roller bearings, spherical ball bearings, spherical roller bearings, single row angular contact bearings, double row angular contact bearings, needle roller bearings, thrust ball bearings, spherical plain bearings, spherical bearings, automotive bearings, pump bearings, and many non-standard bearings are also in our product range. The annual output is more than 10 million sets.
1 . Single box packing, then in carton then in Pallet .
2 . Standard export packing .
3 . According customer demand .
1.you need to pay in advance
2.You can use west union
3.L/C at sight
4.30% T/T in advance . 70% against copy of B/L
Send your inquiry directly to us
