| Place of Origin: | Shandong, China (Mainland) |
| Brand Name: | ZH |
| Certification: | ISO9001:2008 |
| Model Number: | 30308 |
| Minimum Order Quantity: | 1~1000 piece |
|---|---|
| Price: | USD 1.6-1.7 piece |
| Packaging Details: | regular packaging/according client's requst |
| Delivery Time: | 2-30 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 piece days |
| Bore Size: | 40 Mm | Outside Diameter: | 90 Mm |
|---|---|---|---|
| Precision Rating: | P0 P6 P5 P4 P2 | Shipment: | Air Sea |
| Application: | Automobile | Package: | Tube |
| Cage: | Steel Cage | Pricision Grade: | ABEC5/ABEC7 |
| High Light: | precision tapered roller bearings,tapered roller bearings |
||
| Brand | CN&ZH | ||
| Item | Cheap Price Taper Roller Bearing | ||
| Model |
30308 |
||
| Material | chrome steel=GCr15, 52100(ASTM) | ||
| Precision | P0,P2,P4,P5,P6 | ||
| Clearance | C0,C2,C3,C4,C5 | ||
| bore size | 40mm | outer diameter | 90 mm |
| cage type | steel plate | ||
| features | Long-life with high quality | ||
| Low-noise with strict controlling the quality of bearings | |||
| High-load by the advanced high-technical design | |||
| Competitive price, which has the most valuable | |||
| OEM service offered, to meet the customers'requirements | |||
| application | gearbox, auto, reduction box, engine machinery, mining machinery, bicycles, etc. | ||
| package | pallet, wooden case, commercial packaging or as customers' requirement | ||
| price terms | FOB,CFR,CIF,EXW | delivery time | 15-30days according the quantity |
Product Details
Dear my friend, our company has thousands of products, and we cannot display them all at the moment. If you need to leave a message or send an email to us, we will serve you as quickly as possible, thanks! ! !
Specifications
| Bearing No | Principal Dimensions (mm) | Load Ratings KN | Mass | |||||||
| d | D | T | B | C | R min | r min | dyc Cr | stc Cor | kg | |
| 30202 | 15 | 35 | 11.75 | 11 | 10 | 0.6 | 0.6 | 11.76 | 11.28 | 0.054 |
| 30203 | 17 | 40 | 13.25 | 12 | 11 | 1 | 1 | 15.36 | 14.96 | 0.056 |
| 30204 | 20 | 47 | 15.25 | 14 | 12 | 1 | 1 | 24.4 | 26.9 | 0.121 |
| 30205 | 25 | 52 | 16.25 | 15 | 13 | 1 | 1 | 29 | 34 | 0.16 |
| 30206 | 30 | 62 | 17.25 | 16 | 14 | 1 | 1 | 37 | 44 | 0.23 |
| 30207 | 35 | 72 | 18.25 | 17 | 15 | 1.5 | 1.5 | 50.5 | 55 | 0.318 |
| 30208 | 40 | 80 | 19.75 | 18 | 16 | 1.5 | 1.5 | 66 | 73 | 0.43 |
| 30209 | 45 | 85 | 20.75 | 19 | 16 | 1.5 | 1.5 | 70.5 | 83 | 0.464 |
| 30210 | 50 | 90 | 21.75 | 20 | 17 | 1.5 | 1.5 | 72.5 | 74 | 0.55 |
| 30211 | 55 | 100 | 22.75 | 21 | 18 | 2 | 1.5 | 93 | 110 | 0.713 |
| 30212 | 60 | 110 | 23.75 | 22 | 19 | 2 | 1.5 | 104 | 124 | 0.923 |
| 30213 | 65 | 120 | 24.75 | 23 | 20 | 2 | 1.5 | 122 | 147 | 1.14 |
| 30214 | 70 | 125 | 26.25 | 24 | 21 | 2 | 1.5 | 119 | 142 | 1.29 |
| 30215 | 75 | 130 | 27.25 | 25 | 22 | 2 | 1.5 | 139 | 175 | 1.4 |
| 30216 | 80 | 140 | 28.25 | 26 | 22 | 2.5 | 2 | 146 | 178 | 1.56 |
| 30217 | 85 | 150 | 30.5 | 28 | 24 | 2.5 | 2 | 167 | 204 | 2.05 |
| 30218 | 90 | 160 | 32.5 | 30 | 26 | 2.5 | 2 | 222 | 291 | 2.73 |
| 30219 | 95 | 170 | 34.5 | 32 | 27 | 3 | 2.5 | 233 | 300 | 3.27 |
| 30220 | 100 | 180 | 37 | 34 | 29 | 3 | 2.5 | 262 | 340 | 3.56 |
| 30222 | 110 | 200 | 41 | 38 | 32 | 3 | 2.5 | 320 | 430 | 5.27 |
| 30224 | 120 | 215 | 43.5 | 40 | 34 | 3 | 2.5 | 330 | 445 | 6.32 |
| 30226 | 130 | 230 | 43.75 | 40 | 34 | 4 | 3 | 360 | 490 | 7.58 |
| 30228 | 140 | 250 | 45.75 | 42 | 36 | 4 | 3 | 410 | 550 | 8.64 |
| 30230 | 150 | 270 | 49 | 45 | 38 | 4 | 3 | 420 | 560 | 11 |
| 30240 | 200 | 360 | 64 | 58 | 48 | 5 | 4 | 790 | 1100 | 25 |
| 30244 | 220 | 400 | 72 | 65 | 54 | 5 | 4 | 950 | 1350 | 40 |
