Name: GCR15 7003 P4 High Precision Spindle Ball Bearings 7003C HQ1
Brand: QIEAL ZH
SKU: 7003C HQ1 P4
Rating: 4.7 (198 reviews)

Home Products Angular Contact Ball Bearing

GCR15 7003 P4 High Precision Spindle Ball Bearings 7003C HQ1

Product Details:

Place of Origin:	CHINA JAPAN
Brand Name:	QIEAL ZH
Model Number:	7003C HQ1 P4
Certifiexcavatorion:	ISO-9001

Payment & Shipping Terms:

Minimum Order Quantity:	1PCS
Price:	Negotiable
Packaging Details:	Packaging according to customer requirements
Delivery Time:	3-7work days
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	500 per day

Contact Now

Detailed Product Description

Materials:	Chrome Steel/GCR15	Number Of Row:	Single Rows
Material(Ball)-SN24:	Ceramic Ball(Si3N4)	Structure:	Ceramic Ball/Angular Contact Ball
ID:	17 Mm	OD:	35 Mm
B:	10 Mm	Product:	Weight 0.045kg
High Light:	High Precision Spindle Ball Bearings , P4 Spindle Ball Bearings , GCR15 Spindle Ball Bearings

7003 P4 High Precision Spindle Ball Bearings 7003C HQ1 P4

Product Description

Spindle & Precision Machine Tool Angular Contact Bearing - 17 mm ID, 35 mm OD, 10 mm Width, 15 ° Contact, ABEC 7 (ISO Class 4),
ABEC 9 (ISO Class 2), Open

Structure-Ceramic Ball/Angular Contact ball

Model number-7003 HQ1

Materials-Chrome steel/GCR15

Precision grade-P4/P2

Lubriexcavatorion type-Grease lubriexcavatorion

Contact Angle-C=15°;AC=25°

Material(Ball)-SN24:Ceramic ball(Si3N4)

Number of Row-Single rows

Material(Cage)-TN /PN

Combination-

SU:Universal combination (single row)

DU:Universal combination (double rows)
DB: Back-to-back combination
DF: Face-to-face combination
DT: Parallel combination
DBD.DFD.DTD: Three rows
DBB.DFF.DBT.DFT.DTT: Four rows

excavatoregories:Angular Contact Ball Bearings Ceramic Ball Bearings

Related Search:7007AC / CHQ1P4,7007C Ceramic Ball Bearings,7007C Spindle bearing,7007C High Speed Bearing
Product Features
Angular Contact Ball bearing with Ceramic balls (Si3N4), used in high precision Spindle and Motors
Series Introduction
High Speed Ceramic Ball Type:ISO 10 Series - highest load, second lowest speed
bearings-70 Series Angular Contact Bearings Series
Model No.
7000HQ1,7001HQ1,7002HQ1,7003HQ1,7004HQ1,7005HQ1,7006HQ1,7007HQ1,7008HQ1,7009HQ1,
7010HQ1,7011HQ1,7012HQ1,7013HQ1,7014HQ1,7015HQ1,7016HQ1,7017HQ1,7018HQ1
Appliexcavatorions High Speed Ceramic Ball Angular contact bearing appliexcavatorions :
electric motors,Spindle,automotive appliexcavatorions, home appliances, industrialequipment

name	cnc lathe spindle bearing 7003 C P4 grade
ball material	Si3N4
ID	17 mm
OD	35 mm
B	10 mm
Product weight	0.045kg
Cage Material:	TN
material	qireal220929@163.com
Tel	+86-18620602705

GCR15 7003 P4 High Precision Spindle Ball Bearings 7003C HQ1 0

GCR15 7003 P4 High Precision Spindle Ball Bearings 7003C HQ1 4

bearing	d	D	B	c	Da	da	contact angle	weight KG
B7000-C-2RSD-T-P4S-UL	10	26	8	6.4	22	14	15°	0.02
B7001-C-2RSD-T-P4S-UL	12	28	8	6.7	24.5	16.5	15°	0.02
B7002-C-2RSD-T-P4S-UL	15	32	9	7.6	28	19	15°	0.03
B7003-C-2RSD-T-P4S-UL	17	35	10	8.5	32	21	15°	0.04
B7004-C-2RSD-T-P4S-UL	20	42	12	10.2	37	25	15°	0.07
B7005-C-2RSD-T-P4S-UL	25	47	12	10.8	42	30	15°	0.08
B7006-C-2RSD-T-P4S-UL	30	55	13	12.3	49	36	15°	0.11
B7007-C-2RSD-T-P4S-UL	35	62	14	13.5	56	41	15°	0.15
B7008-C-2RSD-T-P4S-UL	40	68	15	14.7	62	46	15°	0.19
B7009-C-2RSD-T-P4S-UL	45	75	16	16	69	51	15°	0.24
B7010-C-2RSD-T-P4S-UL	50	80	16	16.7	74	56	15°	0.25
B7011-C-2RSD-T-P4S-UL	55	90	18	18.7	83	62	15°	0.38
B7012-C-2RSD-T-P4S-UL	60	95	18	19.4	88	67	15°	0.4

GCR15 7003 P4 High Precision Spindle Ball Bearings 7003C HQ1 5

Product packaging

Packing : 1. Industrial packing 2. Single box +carton +pallets /case 3. According to customers demand Delivery time : 1. Generally after payment: within 3 days . 2. If need produce , about 30 days Payment A less USD1000 , 100% T/T in advance . 1. More USD1000 , 30% T/T in advance , 70%T/T before shipment

FAQ

Q: Are you trading company or manufacturer ? A: We are factory and trader .

Q: How long is your delivery time? A: Generally it is 1-3 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ? A: Yes, we could offer the sample for free charge but do not pay the cost of freight. Q: What is your terms of payment ? A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment. If you have another question, pls feel free to contact us .
