Home Products Angular Contact Ball Bearing

Angular Contact Thrust Ball Bearings 35TAC72 35TAC72B30TAC72BSUC10PN7B 35x72x15mm

Product Details:

Place of Origin:	CHINA JAPAN
Brand Name:	QIEAL ZH
Model Number:	35TAC72 35TAC72B 30TAC72BSUC10PN7B
Certifiexcavatorion:	ISO-9001

Payment & Shipping Terms:

Minimum Order Quantity:	1PCS
Price:	Negotiable
Packaging Details:	Packaging according to customer requirements
Delivery Time:	3-7work days
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	500 per day

Contact Now

Detailed Product Description

Bearing Model:	35TAC72 35TAC72B 30TAC72BSUC10PN7B	Emphasize:	Angular Contact Thrust Ball Bearings 35TAC72 35TAC72B30TAC72BSUC10PN7B35
Weight:	0.31 KG	(dxDxB):	35x72x15mm
Structure:	Angular Contact Thrust Ball Bearing	Appliexcavatorion:	Machine Tool
Lead Time:	Within 3 Days	Type:	60° Ball Screw Support Ball Bearing
High Light:	Angular Contact Thrust Ball Bearings , Thrust Ball Bearings 35TAC72

Angular Contact Thrust Ball Bearings 35TAC72 35TAC72B30TAC72BSUC10PN7B35x72x15mm

Product Description

BALL SCREW SUPPORT BEARINGS

Angular Contact Thrust Ball Bearings for Ball Screw Support

High precision angular contact thrust ball bearings to support precision ball screws, have better performance than earlier combinations of angular contact ball bearings or combinations using thrust bearings. They are especially suitable for high precision machine-tool feeding mechanisms and similar appliexcavatorions. TAC B Series (Machine Tool Appliexcavatorions)

TAC02 and 03 Series (Electric Injection Molding Machines)

TAC B and TAC02, 03 Differences

Bearing Model	35TAC72BSUC10PN7B
Appliexcavatorion	Machine Tool
Type	60° Ball Screw Support Ball Bearing
Structure	Angular Contact Thrust Ball Bearing
(dxDxB)	35x72x15mm
Weight	0.31 KG
Lead Time	Within 3 Days
Contact	chen (Ms)
SKYPE	qiear bearing
WhatsApp / Webchat	+86 18620602705
Email	qireal220929@163.com

Angular Contact Thrust Ball Bearings for Supporting Screw
Model No.	d(mm)	D(mm)	B(mm)
30TAC62BDDG	30	62	12
35TAC72BDDG	35	72	15
40TAC72BDDG	40	72	15
40TAC90BDDG	40	90	20
45TAC100BDDG	45	100	20
15TAC02AT85	15	35	11
25TAC02AT85	25	32	15
TAC35-2T85	35	90	23
40TAC03AT85	40	90	23
45TAC03AT85	45	100	25
TAC45-2T85	45	110	27
50TAC03AT85	50	110	27
55TAC03AT85	55	120	29
60TAC03AT85	60	130	31
80TAC03AM	80	170	39
100TAC03CMC	100	215	47
120TAC03CMC	120	260	55
760202TN1	15	35	11
760203TN1	17	40	12
760204TN1	20	47	14
760205TN1	25	52	15
760206TN1	30	62	16
760207TN1	35	72	17
760208TN1	40	80	18
760209TN1	45	85	19
760210TN1	50	90	20
760211TN1	55	100	21
760212TN1	60	110	22
760213TN1	65	120	23
760214TN1	70	125	24
760215TN1	75	130	25
760216TN1	80	140	26
760217TN1	85	150	28
760218TN1	90	160	30
760219TN1	95	170	32

Product packaging

Packing : 1. Industrial packing 2. Single box +carton +pallets 3. According to customers demand Delivery time : 1. Generally after payment: within 3 days . 2. If need produce , about 30 days Payment A less USD1000 , 100% T/T in advance . 1. More USD1000 , 30% T/T in advance , 70%T/T before shipment

Shipping

PACKING:bag+box+carton+pallet/wooden case.

Shipping : by sea/by air/by express like EMS FEDEX TNT DHL...

FAQ

Q: Are you trading company or manufacturer ?
A: We are factory and trader .
Q: How long is your delivery time?
A: Generally it is 1-3 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to
quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us as below:
