Place of Origin:
CHINA
Brand Name:
Z&H
Model Number:
7005 AC
Quick Details
Structure | Angular contact |
Type | Ball |
Brand Name | Z&H |
Circle Material | GCR15 |
Cage Material | steel/brass |
Bore Size | 10 - 160 mm |
Outside Diameter | 26 - 290mm |
Model series | 7000AC,7200AC |
Clearance | C2, C3,C4,C5 |
Vibration | V1 V2 V3 V4 |
Hardness | HRC58-62 |
Precision Rating | P0 P6 P5 |
Place of Origin | Shandong, China (Mainland) |
Samples | Free |
Certifiexcavatore | ISO9001:2008 |
OEM service | available |
Supplying ability | great number with stock and new products |
Stock | Large stock |
Other model
Model No. | d(mm) | D(mm) | H(mm) | Cr(kN) | Cor(kN) |
grease lubriexcavatorion (r/min) |
oil lubriexcavatorion (r/min) |
W(kg) |
7000C | 10 | 26 | 8 | 5.30 | 2.45 | 47000 | 62000 | 0.021 |
7200C | 10 | 30 | 9 | 5.00 | 2.35 | 40000 | 54000 | 0.031 |
7001C | 12 | 28 | 8 | 5.80 | 2.95 | 40000 | 54000 | 0.024 |
7001AC | 12 | 28 | 8 | 5.40 | 2.75 | 29000 | 37000 | 0.024 |
7201C | 12 | 32 | 10 | 7.90 | 3.85 | 38000 | 50000 | 0.038 |
7201AC | 12 | 32 | 10 | 7.45 | 3.65 | 27000 | 34000 | 0.038 |
7002C | 15 | 32 | 9 | 6.60 | 3.70 | 35000 | 47000 | 0.035 |
7002AC | 15 | 32 | 9 | 6.10 | 3.45 | 26000 | 32000 | 0.035 |
7202C | 15 | 35 | 11 | 8065 | 4.55 | 33000 | 43000 | 0.048 |
7202AC | 15 | 35 | 11 | 8.10 | 4.25 | 24000 | 29000 | 0.048 |
7003C | 17 | 35 | 10 | 7.30 | 4.45 | 31000 | 41000 | 0.045 |
7003AC | 17 | 35 | 10 | 6.75 | 4.15 | 23000 | 28000 | 0.045 |
7203C | 17 | 40 | 12 | 10.9 | 5.90 | 29000 | 38000 | 0.070 |
7203AC | 17 | 40 | 12 | 10.2 | 5.50 | 21000 | 26000 | 0.070 |
7004C | 20 | 42 | 12 | 11.1 | 6.60 | 26000 | 35000 | 0.079 |
7004AC | 20 | 42 | 12 | 10.3 | 6.10 | 19000 | 24000 | 0.079 |
7204C | 20 | 47 | 14 | 15.5 | 9.00 | 24000 | 32000 | 0.112 |
7204AC | 20 | 47 | 14 | 14.5 | 8.40 | 17000 | 22000 | 0.112 |
7204B | 20 | 47 | 14 | 13.3 | 7.70 | 13000 | 17000 | 0.112 |
7005C | 25 | 47 | 12 | 12.3 | 8.00 | 23000 | 30000 | 0.091 |
Appliexcavatorion
Single-Direction thrust Ball bearing is widely used in Parts which bear Axial Load of one side , Low speed .For example : Crane hook, Vertical pumps, Vertical centrifuge, Jack, Low Speed Reducer .
Our company
Linqing zhonghong bearing co., LTD. Is a company with bearing production and sales, our company has many years of bearing support and industrial service experience in the industrial field. The company specializes in imported bearings, including Swedish bearing, German FAG bearing. Japan NSK bearing, NTN bearing, KOYO bearing, American TIMKEN bearing, etc. Domestic brands include: ZWZ bearing. Harbin HRB bearing, luoyang etc. Involving type: deep groove ball bearings, self-aligning ball bearings, cylindrical roller bearing, spherical roller bearings, angular contact bearings, tapered roller bearings, thrust ball bearings, thrust roller bearings, needle roller bearings, joint bearings, outer spherical bearings, bearing special appliexcavatorions.
We seek development by reputation, benefit from management, and use service to compete with customers.Over the years,with good reputation and excellent quality, a complete set of sales system has been established, which has established long-term cooperative relations with hundreds of customers throughout the country.
Why choose us
1. in the same price , our quality is higher , in the same quality , our price is lower.
2.high precision , long life.
3. our brand is WZA , we also can OEM.
4.best service ,many stocks.
5.for large quantity bearings , our delivery time is shorter than other factory .
in normal , if the quantity is between 100000-1000000 , the delivery time is 10-35 days .
