Innovate ZH Bearing,
and Rotate the Peak of Bearing World！
Begins with customer needs ,and finally customer satisfaction.
Sales & Support:
 |
| Place of Origin: | CHINA |
| Brand Name: | CN&ZH |
| Certification: | ISO9001:2008 |
| Model Number: | 24038MB |
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton |
| Delivery Time: | 1-2 work day |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 500 per day |
| Product Name: | Spherical Roller Bearing | Model: | 24038MB |
|---|---|---|---|
| Packing: | Neutral Packing | Weight: | 22.95kg |
| Brand Name: | CN&ZHor OEM | Material: | GCR15 Material (Chrome Steel) |
| The Number Of Rows: | Double | Cage Type: | Ca Cc E MB |
| High Light: | split roller bearing,spherical roller thrust bearing |
||
Oem Service Spherical Roller Bearing 24032 MB /W33 with Great Endurance
Spherical roller bearings have barrel-shaped rollers between the inner ring, which has two raceways, and the outer ring which has one spherical raceway. Since the center of curvature of the outer ring raceway surface coincides with the bearing axis, they are self-aligning in a manner similar to that of self-aligning ball bearings. Therefore, if there is deflection of the shaft or housing or misalignment of their axes, it is automatically corrected so excessive force is not applied to the bearings.
| Brand |
CN&ZH
|
|
| Series |
Spherical roller bearing
|
|
| Bearing NO. |
24038 MB
|
|
| Basic size mm |
ID |
190
|
| OD |
290 |
|
| WIDE |
100 |
|
| Basic load ratings Kn |
Cr |
975
|
| Cor |
1910 |
|
| Limiting Speeds N(1/min) |
Grease |
800
|
| Oil |
1100
|
|
| Payment Term | 1).30%T/T in advance ,70% balance has to be paid before first shippment. 2).100% L/C at sight 3): West Union 4): PayPal 5): Other payment terms depend on our discussion |
|
Application
Continuous Casting Machines
Mechanical Fans and Blowers
Gearbox and Pumps
Wind Turbines
Material Handling
Marine Propulsion and Offshore Drilling
Mining and Construction Equipment
Pulp and Paper Processing Equipment
I look forward to working with you for a long time
