Innovate ZH Bearing,
and Rotate the Peak of Bearing World！
Begins with customer needs ,and finally customer satisfaction.
Sales & Support:
 |
| Place of Origin: | CHINA |
| Brand Name: | QIEAL ZH |
| Model Number: | 11BC |
| Certifiexcavatorion: | ISO-9001 |
| Minimum Order Quantity: | 1PC |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Wooden case,or on request,By carton |
| Delivery Time: | 2-7 work days |
| Payment Terms: | L/C,D/A,D/P,T/T, Western Union, Alibaba online payment,Paipal,etc. |
| Supply Ability: | 100 per day |
| Part Name: | Travel Motor Assy | MOQ: | 1 Pcs |
|---|---|---|---|
| Type: | Excavator Spare Parts | After-sales Service Provided: | Online Support |
| Warranty: | 6 Months | Showroom Loexcavatorion:: | None |
| Color: | As The Photo | Packing: | Standard Export Package,on Request. |
| Transportation: | Ship/Air Transportation,Express Delivery | ||
| High Light: | GM05 Excavator Spare Parts,PC45 Excavator Spare Parts,TM05 Final Drive |
||
Tapered roller bearings mainly burden the joint load from radial and shaft side. This kind of bearings has strong load capability. It belongs to separated bearing; its inner components and outer components can be equipped individually.On small and medium sized dimensions, our tapered roller bearings use P5 or equivalent techniques; and adopt entire convexity design.
Features
The inner and outer ring raceways and rollers of these bearings are made with a taper so that the surface planes of the raceways and roller axis meet at a point.The rollers are guided by a flange on the inner ring.Tapered roller bearings are separable, and have the following components: outer ring,inner ring and roller assembly. The non-separable inner ring and roller assembly is called the 'cone', and the outer ring is called the 'cup'. Internal clearanceis established during mounting by the axial position of the cone relative to the cup.
Appliexcavatorions
Mainly used in motorcycle rear axle wheel hub, heavy machine tools' main shafts, big power reduction gears, axletree axle boxes, roller wheels of transportation devices, and the supporting rollers and working rollers of the
rolling mills.
Other Model:
| Specifiexcavatorion | Boundarydimentions(mm) | ||||
| d | D | B | |||
| 5BC | 28.313 | 0.0154 | |||
| 11BC | 33.297 | 0.0275 | |||
| 09067/09195 | 19.050 | 49.225 | 18.034 | 0.1804 | |
| 09081/091195 | 20.625 | 49.225 | 19.845 | 0.1555 | |
| LM11749/LM11710 | 17.462 | 39.878 | 13.843 | 0.0830 | |
| LM11949/LM11910 | 19.050 | 45.237 | 15.494 | 0.1250 | |
| M12649/M12610 | 21.430 | 50.005 | 17.526 | 0.1740 | |
| LM12748/LM12710 | 21.430 | 45.237 | 15.494 | 0.1180 | |
| LM12749/LM12710 | 22.000 | 45.237 | 15.494 | 0.1160 | |
| LM12749/LM12711 | 22.000 | 45.975 | 15.494 | 0.1210 | |
| 14125A/14276 | 31.750 | 69.012 | 19.845 | 0.3540 | |
| 14137A/14276 | 34.925 | 69.012 | 19.845 | 0.3310 | |
| 14138A/14276 | 34.925 | 69.012 | 19.845 | 0.3290 | |
| 25877/25821 | 34.925 | 73.025 | 23.812 | 0.4730 | |
| 25880/25821 | 36.487 | 73.025 | 23.812 | 0.4580 | |
| 2785/2720 | 33.338 | 76.200 | 23.812 | 0.5440 | |
| 2788/2720 | 38.100 | 76.200 | 23.812 | 0.4990 | |
| 2788/2729 | 38.100 | 76.200 | 23.812 | 0.5030 | |
| 2790/2720 | 33.338 | 76.200 | 23.812 | 0.5490 | |
| 2790/2729 | 33.338 | 76.200 | 23.812 | 0.5550 | |
| 28580/28521 | 50.800 | 92.075 | 24.608 | 0.7070 | |
| 28584/28521 | 52.388 | 92.075 | 24.608 | 0.6820 | |
|
Specifiexcavatorion
|
dimensions(mm)
d D B |
Mass(kg)
|
||
|
30202
|
15
|
35
|
11.75
|
0.053
|
|
30203
|
17
|
40
|
13.25
|
0.079
|
|
30204
|
20
|
47
|
15.25
|
0.127
|
|
30205
|
25
|
52
|
16.25
|
0.157
|
|
30206
|
30
|
62
|
17.25
|
0.238
|
|
30207
|
35
|
72
|
18.25
|
0.34
|
|
30208
|
40
|
80
|
19.75
|
0.438
|
|
30209
|
45
|
85
|
20.75
|
0.488
|
|
30210
|
50
|
90
|
21.75
|
0.558
|
|
30211
|
55
|
100
|
22.75
|
0.736
|
|
30212
|
60
|
110
|
23.75
|
0.93
|
|
30213
|
65
|
120
|
24.75
|
1.18
|
|
30214
|
70
|
125
|
26.25
|
1.3
|
|
30215
|
75
|
130
|
27.25
|
1.43
|
|
30216
|
80
|
140
|
28.25
|
1.69
|
|
30217
|
85
|
150
|
30.5
|
2.12
|
|
30218
|
90
|
160
|
32.5
|
2.6
|
|
30219
|
95
|
170
|
34.5
|
3.13
|
|
30220
|
100
|
180
|
37
|
3.78
|
|
30221
|
105
|
190
|
39
|
4.52
|
|
30222
|
110
|
200
|
41
|
5.28
|
|
30224
|
120
|
215
|
43.5
|
6.28
|
|
30226
|
130
|
230
|
43.75
|
6.83
|
|
30302
|
15
|
42
|
14.25
|
0.098
|
|
30303
|
17
|
47
|
15.25
|
0.134
|
|
30304
|
20
|
52
|
16.25
|
0.172
|
|
30305
|
25
|
62
|
18.25
|
0.27
|
|
30306
|
30
|
72
|
20.75
|
0.403
|
|
30307
|
35
|
80
|
22.75
|
0.538
|
|
30308
|
40
|
90
|
25.25
|
0.758
|
|
30309
|
45
|
100
|
27.25
|
1.01
|
|
30310
|
50
|
110
|
29.25
|
1.28
|
|
30311
|
55
|
120
|
31.5
|
1.63
|
|
30312
|
60
|
130
|
33.5
|
2.03
|
|
30313
|
65
|
140
|
36
|
2.51
|
|
30314
|
70
|
150
|
38
|
3.03
|
|
30315
|
75
|
160
|
40
|
3.63
|
|
30316
|
80
|
170
|
42.5
|
4.27
|
|
30317
|
85
|
180
|
44.5
|
5.08
|
|
30318
|
90
|
190
|
46.5
|
5.67
|
|
30319
|
95
|
200
|
49.5
|
6.55
|
|
30320
|
100
|
215
|
51.5
|
7.94
|
