Home ProductsSpherical Roller Bearing

NTN NSK Spherical Roller Bearing 20315MB/W33 20135CA/W33 75x160x37mm

NTN NSK Spherical Roller Bearing 20315MB/W33 20135CA/W33 75x160x37mm

    • NTN NSK Spherical Roller Bearing 20315MB/W33 20135CA/W33 75x160x37mm
    • NTN NSK Spherical Roller Bearing 20315MB/W33 20135CA/W33 75x160x37mm
    • NTN NSK Spherical Roller Bearing 20315MB/W33 20135CA/W33 75x160x37mm
    • NTN NSK Spherical Roller Bearing 20315MB/W33 20135CA/W33 75x160x37mm
  • NTN NSK Spherical Roller Bearing 20315MB/W33 20135CA/W33 75x160x37mm

    Product Details:

    Place of Origin: China
    Brand Name: Z&H
    Certification: ISO9001:2008
    Model Number: 20319MB

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiable
    Price: Negotiable
    Packaging Details: 1.Single box packing, then in carton then in Pallet. 2.Standard export packing. 3. According customer demand.
    Delivery Time: 2-5days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 3000piece
    Contact Now
    Detailed Product Description
    Bearing No: 20315MB/W33 Material: GCR15/SAE52100
    ID: 75mm High: 37mm
    Weight: 3.76KG Cage: Brass
    Feature: High Speed Seals Type:: CC CA MB MA
    Precision Rating: P0 P6 P5 P4 Warranty: 6month

    Application:



    agricultural machinery to conveying equipment robotics



    dental equipment



    elevators



    rolling mills



    ship rudder shafts



    and aggregate crushers



    among others



    Features:



    Support radial and oscillating axial loads



    C3 radial clearance allows thermal expansion for continuous operating temperatures up to 200 degrees C/392 degrees



    Tapered bore with 1:12 taper for compensating for a flexing shaft or fitting to a tapered shaft



    Roller-guided brass cage evenly spaces rollers for reduced friction, vibration, and noise



    Open design, circumferential groove and three lubrication holes in the outer ring allow for lubrication in place

    NTN NSK Spherical Roller Bearing 20315MB/W33 20135CA/W33 75x160x37mm
    Size list
    Bearing number dimension(mm) weight(kg)
    22306 30*72*19 0.37
    22307 35*80*31 0.75
    22308 40*90*33 1.03
    22309 45*90*33 1.4
    22310 50*110*40 1.85
    22311 55*120*43 2.42
    22312 60*130*46 3
    22313 65*140*48 3.65
    22314 70*150*51 4.4
    22315 75*160*55 5.47
    22316 80*170*58 6.63
    22317 85*180*60 7.07
    22318 90*190*64 8.76
    22319 95*200*67 9.93
    22320 100*215*73 13.7
    22322 110*240*80 17.7
    22324 120*260*86 22.9
    22326 130*280*93 28.5
    22328 140*300*102 35.5
    22330 150*320*108 42
    22332 160*340*114 52.2
    22334 170*360*120 60.7
    22336 180*380*126 72.6
    22338 190*400*132 84.2
    22340 200*420*138 94.4
    22344 220*460*145 119



    PRODUCT SHOW
    NTN NSK Spherical Roller Bearing 20315MB/W33 20135CA/W33 75x160x37mm
    NTN NSK Spherical Roller Bearing 20315MB/W33 20135CA/W33 75x160x37mm

    NTN NSK Spherical Roller Bearing 20315MB/W33 20135CA/W33 75x160x37mm
    NTN NSK Spherical Roller Bearing 20315MB/W33 20135CA/W33 75x160x37mm

    COMPANY INTRODUCTION



    Zhonghong bearing manufacturing co., Ltd is a bearing production,



    sales - based company, the company in the industrial field has many years of bearing supporting and industrial service experience.



    Types involved: deep groove ball bearings, joint bearings, conical bearings, cylindrical bearings and so on Our products are widely used in machine tools,



    coal mine, railway, petroleum printing, power plant, ship, aviation, automobile and other industries



    INSPECTION MACHINE



    NTN NSK Spherical Roller Bearing 20315MB/W33 20135CA/W33 75x160x37mm

    NTN NSK Spherical Roller Bearing 20315MB/W33 20135CA/W33 75x160x37mm



    WAREHOUSE PICTURE



    NTN NSK Spherical Roller Bearing 20315MB/W33 20135CA/W33 75x160x37mm



    NTN NSK Spherical Roller Bearing 20315MB/W33 20135CA/W33 75x160x37mm



    EXHIBITION PICTURE



    NTN NSK Spherical Roller Bearing 20315MB/W33 20135CA/W33 75x160x37mm



    NTN NSK Spherical Roller Bearing 20315MB/W33 20135CA/W33 75x160x37mm



    NTN NSK Spherical Roller Bearing 20315MB/W33 20135CA/W33 75x160x37mm



    Quality Certificates





    NTN NSK Spherical Roller Bearing 20315MB/W33 20135CA/W33 75x160x37mm



    NTN NSK Spherical Roller Bearing 20315MB/W33 20135CA/W33 75x160x37mm



    Quality seervices



    Products process: Advanced producing equipment, inspection equipment and good control system to keep the



    product produce smoothly.



    Quality guaranty: Product quality assurance period is over year 2000 miles.



    Superficial finish: Carefully work in the assembly line to confirm the products in perfect appearance.Products



    can also be manufactured according to drawings and samples with customers requirement. We sincerely



    welcome our friends to visit and negotiate business.



    Meanwhile, we are looking forward to finding long-term partners..





    packaging



    1 . Industrial tube packing + cartons + pallets



    2 . Individual colorful or white box + carton + pallets



    3 . As the clients ' requirement

    NTN NSK Spherical Roller Bearing 20315MB/W33 20135CA/W33 75x160x37mm

    NTN NSK Spherical Roller Bearing 20315MB/W33 20135CA/W33 75x160x37mm

    NTN NSK Spherical Roller Bearing 20315MB/W33 20135CA/W33 75x160x37mm







    RFQ





    1. What is the producing process?


       Production process including raw material cutting, machine processing, grinding, accessories cleaning, assemble, cleaning, stoving, oil coating, cover pressing, testing, package.



    2. How to control the products quality?


      Combining advanced equipment and strict management, we provide high standard and quality bearings for our customers all over the world.



    3. What is the transportation?


     If small quantity , we Suggest to send by express, such as DHL,UPS, TNT FEDEX. If large amount, by shipping.



    4. Can we design packaging?


      Yes. Default is regular packing, and we can make customer's own packing.

    5.  Can you provide OEM service?


     Yes, we work on OEM orders. Which means size, quantity, design, packing solution, etc will depend on your requests; and your logo will be customized on our products.



    6.  Could you tell me the delivery time of your goods?



    3-7 days stock goods and other goods according to the quantity about 3-21 days.



    7.  Can you give me discount on bearing?



      Yes, of course. Pls. send me your Email, you’ll get more
