Innovate ZH Bearing,
and Rotate the Peak of Bearing World!
Place of Origin: | CHINA |
Brand Name: | SKF NTN |
Certification: | ISO9001-2000 / CE / ROHS / UL / SGS |
Model Number: | 23120MB/W33 |
Minimum Order Quantity: | 1pcs |
---|---|
Price: | negotiable |
Packaging Details: | neutral package |
Delivery Time: | 4-7work days |
Payment Terms: | L/C, D/A, D/P, T/T |
Supply Ability: | 300pieces per day |
Product Name: | Spherical Roller Bearing | Old Model: | 23120MB/W33 |
---|---|---|---|
Weight: | 6.5 Kg | Material: | Gcr15 |
Certification:: | ISO9001, ISO14001 | Cage: | Brass Cage |
ID: | 100 | OD: | 165 |
High: | 52 | Precision Rating: | P0 P6 P5 P4 |
Clearance: | C0 C2 C3 C4 | Applicable Industries: | Food, Textile, Mining, Rolling Mill |
Place Of Origin: | Shang Dong (China) | Feature: | High Speed |
Service: | OEM | ||
High Light: | roller cage bearing,spherical roller thrust bearing |
Spherical roller thrust bearings
incorporate a large number of asymmetrical rollers and have specially designed raceways with an optimum conformity. They can therefore support very heavy axial loads and permit relatively high speed operation.
spherical roller thrust bearings are produced in two designs depending on the size and series. Bearings up to and including size 68 identified by the designation suffix E have a pressed steel window-type cage which,
with the rollers, forms a non-separable assembly with the shaft washer. All other bearings have a machined brass or steel cage which is guided by a sleeve held in the shaft washer bore.
29412 E 29413E 29414 E 29415 29416 29317 29417 E E1. MB
29318 29418 29320 29420 29322 29422 29324 29424 E E1.MB
29326 29426 29328 29428 29230 29330 29430 E E1.MB
29332 29432 29334 29434 29236 29336 29436 E
29338 29438 29240 29340 29440 29244 29344 29444 E
29248 29348 29448 29252 29352 29452 29256 E
23218 23220 23222 23224 23226 23228 23230 23232 23234 CA/W33
23236 23238 23240 23244 23248 23252 23256 23260 23264 23268 CAK/W33
23272 23276 23280 23284 23292 23296 232/500 232/750 CA/W33
23120 23121 23122 231234 23126 23128 23130 CA/W33
23132 23134 23136 23138 23140 23144 23148 23152 CAK/W33
23156 23160 23164 23168 23172 23176 23180 CA/W33
24036 24038 24040 24044 24048 24052 24056 24060 24064 CAK/W33
24068 24072 24076 24080 24084 24092 CAD/W33
240/850 CAF1/W33s
24122 24124 24126 24128 24130 24132 24134 24136 24138 CA/W33
24140 24144 24148 24152 24156 24160 24164 24168 24172 CA/W33
24192 241/560 241/600 241/710 W33
Product name |
Spherical roller bearing 23120 CA MB W33
|
Brand |
NSK NTN and other brand
|
Basic size mm |
Inner diameter:100 Outer diameter:165 Width:52 |
Material |
Chrome Steel ,Carbon steel,Stainless steel
|
Number of Row |
Single Row
|
Place of Origin |
China (Mainland)
|
Clearance |
C0, C2, C3, C4, C5
|
1.Spherical Roller Bearing Information:
Roller bearings use rolling elements to maintain the separation between moving parts to reduce rotational friction and support radial and axial loads.
These elements can be one of the following types: ball, cylindrical, spherical, barrel, needle, spindle, or tapered. All roller bearings are open, shielded,
or sealed.Sealed bearings are lubricated with oil or grease in the bearing factory, while open and shielded bearings are meant to be lubricated in place,
with periodic reapplication of lubrication, based on use. The shield protects the working parts of the bearing from environmental debris that may be introduced and could reduce the ball bearing speed and lifespan.
2.Application:
agricultural machinery to conveying equipment,
robotics,
dental equipment,
elevators,
rolling mills,
ship rudder shafts,
and aggregate crushers,
among others.
3.Features:
Support radial and oscillating axial loads
C3 radial clearance allows thermal expansion for continuous operating temperatures up to 200 degrees C/392 degrees
Tapered bore with 1:12 taper for compensating for a flexing shaft or fitting to a tapered shaft
Roller-guided brass cage evenly spaces rollers for reduced friction, vibration, and noise
Open design, circumferential groove and three lubrication holes in the outer ring allow for lubrication in place
4.Quality&Services
Products process: Advanced producing equipment, inspection equipment and good control system to keep the product produce smoothly.
Quality guaranty: Product quality assurance period is over year 2000 miles.
Superficial finish: Carefully work in the assembly line to confirm the products in perfect appearance.Products can also be manufactured according to drawings and samples with customers requirement. We sincerely welcome our friends to visit and negotiate business.
Meanwhile, we are looking forward to finding long-term partners..
2 . Other size :
Bearing No. | Boundary dimensions | Basic load ratings(kN) | Limiting speeds | Mass | |||||
mm | Dynamic | Static | rpm | Kg | |||||
d | D | B | rs min | Cr | Cor | Grease | Oil | ||
23130 | 150 | 250 | 80 | 2.1 | 730 | 1,190 | 1,100 | 1,700 | 15.6 |
23130K | 150 | 250 | 80 | 2.1 | 730 | 1,190 | 1,100 | 1,700 | 15.1 |
23130KW33C3 | 150 | 250 | 80 | 2.1 | 730 | 1,190 | 1,100 | 1,700 | 15.1 |
23130W33C3 | 150 | 250 | 80 | 2.1 | 730 | 1,190 | 1,100 | 1,700 | 15.6 |
23132 | 160 | 270 | 86 | 2.1 | 840 | 1,370 | 1,000 | 1,600 | 19.8 |
23132K | 160 | 270 | 86 | 2.1 | 840 | 1,370 | 1,000 | 1,600 | 19.2 |
23132KW33C3 | 160 | 270 | 86 | 2.1 | 840 | 1,370 | 1,000 | 1,600 | 19.2 |
23132W33C3 | 160 | 270 | 86 | 2.1 | 840 | 1,370 | 1,000 | 1,600 | 19.8 |
23134 | 170 | 280 | 88 | 2.1 | 885 | 1,490 | 960 | 1,500 | 21.5 |
23134K | 170 | 280 | 88 | 2.1 | 885 | 1,490 | 960 | 1,500 | 20.8 |
23134KW33C3 | 170 | 280 | 88 | 2.1 | 885 | 1,490 | 960 | 1,500 | 20.8 |
23134W33C3 | 170 | 280 | 88 | 2.1 | 885 | 1,490 | 960 | 1,500 | 21.5 |
23136 | 180 | 300 | 96 | 3 | 1,030 | 1,730 | 900 | 1,400 | 25.1 |
23136K | 180 | 300 | 96 | 3 | 1,030 | 1,730 | 900 | 1,400 | 24.2 |
3 . CONPANY PROFILE
ZhongHong Bearing Manufacturing Co. Ltd is a bearing production, sales - based company,
the company in the industrial field has many years of bearing supporting and industrial service experience.
Types involved: deep groove ball bearings, joint bearings, conical bearings, cylindrical bearings and so on Our products are widely used in machine tools,
coal mine, railway, petroleum printing, power plant, ship, aviation, automobile and other industries
WORKSHOP
WAREHOUSE
INSPECTION MACHINE
4. PACKAG and SHIPPING
1.Single box packing, then in carton then in Pallet.
2.Standard export packing.
3. According customer demand.
4. Negotiable
5 . FAQ
Q: Why do we choose your company?
A: We always insist quality first. We have our bearing factory, therefore we have advantage in quality control and price of one way clutch bearing.
Q:What is the delivery time?
A: Most of the bearing we have stock. For small quantity, we will arrange delivery within 15 days.
Q: What is your payment term?
A: Our payment term include L/C, T/T, Western Union, Paypal etc.
Q: Can you send bearing samples first?
A: Yes, we can send bearing samples of one way clutch bearing to check quality first.
