NU1014M Cylindrical Roller Bearing Without Edge And Brass Cage Sizes 70*110*20mm

NU1014M Cylindrical Roller Bearing Without Edge And Brass Cage Sizes 70*110*20mm

    • NU1014M Cylindrical Roller Bearing Without Edge And Brass Cage Sizes 70*110*20mm
    • NU1014M Cylindrical Roller Bearing Without Edge And Brass Cage Sizes 70*110*20mm
    • NU1014M Cylindrical Roller Bearing Without Edge And Brass Cage Sizes 70*110*20mm
    • NU1014M Cylindrical Roller Bearing Without Edge And Brass Cage Sizes 70*110*20mm
  • NU1014M Cylindrical Roller Bearing Without Edge And Brass Cage Sizes 70*110*20mm

    Product Details:

    Place of Origin: ShanDong, China (Mainland)
    Brand Name: CN&ZH
    Certification: ISO 9001:2000
    Model Number: NN3010K

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 piece
    Price: USD 5-5.6 piece
    Packaging Details: Conventional Package/As your request
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 5000 pieces days
    Contact Now
    Detailed Product Description
    Bore Size: 70 Mm Outside Diameter: 110 Mm
    Lubrication: Oil,Grease,Dry Feature: High Quality/Long Life
    Material: Chrome Steel/GCR 15 Precision Rating: P0 P6 P5 P4 P2

    NU1014M Cylindrical Roller Bearing Without Edge And Brass Cage Sizes 70*110*20mm

    1.The Introduction of Cylindrical Roller Bearing :

    Rolling element is a cylindrical roller to the heart of rolling bearings. Cylindrical roller bearing internal structure of the roller was 90 ° perpendicular to each other cross-arranged (which is the origin of the name of cross-roller bearings), the gap between the roller with cage or isolator block can prevent the roller tilt or roller Between the grinding, effectively preventing the increase of the rotation torque.

    2.The Features of Cylindrical Roller Bearing :

    1. Roller and raceway for line contact or repair offline contact, radial bearing capacity, suitable for heavy load and impact load.
    2. Friction coefficient is small, suitable for high-speed, speed close to the deep groove ball bearings.
    3.N-type and NU-type axial movement, can adapt to thermal expansion or installation error caused by the relative position of the shaft and shell changes, can be used for free-end support.
    4. Shaft or seat hole processing requirements are higher, the relative deviation of the outer ring axis after installation to strict control, so as not to cause contact stress concentration.
    5. Inner or outer ring can be separated, easy to install and remove.



    3.The Application of Cylindrical Roller Bearings :

    Drilling machines, steam-driven pumps, rubber granulation machine, extrusion equipment, medicinal crushing machinery, textile equipment and equipment, plastic machine, planting machine, deep hole drilling, dispensing equipment, box-type drying equipment, steel wire drawing machine, Water-cooled chillers, bakery equipment, high-frequency welding, sewage pumps, eyelets machines, plastic sheet equipment, and so on purpose.




    4.Related Roller Bearing Catalogue:



    BEARING CODE DIMENSION mm
    NU NJ NUP d D B KG
    NU204 NJ204 NUP204 20 47 14 0.14
    NU204M NJ204E NUP204E 20 47 14 0.14
    NU2206 NJ2206 NUP2206 30 62 20 0.29
    NU2206M NJ2206M NUP22206M 30 62 20 0.26
    NU304 NJ304 NUP304 20 52 15 0.201
    NU304M NJ304M NUP304E 20 52 15 0.201
    NU2306 NJ2306 NUP2306 30 72 27 0.60
    NU2306E NJ2306E NUP2306E 30 72 27 0.599
    NU205 NJ205 NUP205 25 52 15 0.148
    NU205M NJ205E NUP205E 25 52 15 0.155
    NU2205 NJ2205 NUP2205 25 62 18 0.168
    NU2205E NJ2205E NUP2205E 25 62 18 0.168
    NU305 NJ305 NUP305 25 62 17 0.284
    NU305M NJ305E NUP305E 25 62 17 0.284
    NU2305 NJ2305 NUP2305 25 62 24 0.45
    NU2305E NJ2305E NUP2305E 25 62 24 0.379
    NU406 N6405 NUP406 30 90 23 0.90



    Package&Delivery



    Packaging Detail: 1.industrial packaging: plastic bag+kcraft paper+carton+plywood pallets;
    plastic tube+carton+plywood pallets
    2.commerical packaging: 1pc/plastic bag+color box+carton+plywood pallets
    3.as client's requirement
    Delivery Detail: 7-35 days
